[ AREAS-642 ]


  • All kind of washers

  • DIN 6319 Spherical washers/ GB/T 849 washers

  • Lockwashers DIN 5406 / DIN 2093

  • DIN 9021/ISO 7093-1 Large Series Flat Washers 200HV

  • Din 7967 Counter Nut (Also Known As Pal® Nuts)

  • DIN 6797/6798

  • DIN434 square bevel washer

  • DIN435 square bevel washe

  • Nord Lock Washer/Washers-Wedge lock

NORD-LOCK WASHERS

Image result for nord lock washerImage result for nord lock washer
 33.53,5*44*55*66*1/4”1/4”*88*3/8"3/8"*1010*7/16"1212*1/2"1/2"*1414*1616*1818*3/4"3/4"*2020*2222*2424*1"1"*2727*3030*3333*3636*39424548
Ø13.43.93.94.44.45.45.46.56.57.27.28.78.710.310.310.710.711.4131313.513.515.215.2171719.519.5202021.421.423.423.425.325.327.927.928.428.431.431.434.434.437.437.440.443.246.249.6
Ø077.697.69910.810.813.511.513.513.516.616.62118.519.525.419.525.42330.725.430.72934.530.73930.73934.5423948.53948.54248.54758.548.558.548.558.5556358.5637075
T zincflake/A41,8/2,21,8/2,21,8/2,21,8/2,21,8/2,21,8/2,21,8/2,21,8/2,22,5/2,21,8/2,22,5/2,22,5/2,22,5/2,22,5/2,22,5/2,22,5/2,22,5/2,22,5/2,22,5/2,03,4/3,02,5/2,23,4/3,23,4/3,23,4/3,23,4/3,23,4/3,23,4/3,23,4/3,23,4/3,23,4/3,23,4/3,23,4/3,23,4/3,24,6/3,23,4/3,23,4/3,23,4/3,24,6/3,26,6/6,86,6/6,86,6/6,86,6/6,86,6/6,86.66,6/6,86.66,6/6,86.677

LOCK WASHER FOR SHAFTS WITHOUT GROOVE

Lock washer for shafts without groove
d2,02.43,03,04,04,05,05,06,07,08,09,09.510,010,011,012,014,018,020,0
D±0,209.79.79.79.511.511.311.51515.31515.318.418.418.421212528.236.636.6
d11,61-1,842,02-2,252,58-2,812,50-2,653,57-3,803,50-3,654,51-4,744,50-4,655,45-5,706,50-6,657,40-7,668,50-8,759,00-9,269,49-9,749,50-9,6510,50-10,6511,37-11,6213,40-13,6617,34-17,6219,30-19,63
H±0,151.31.31.31.21.31.21.31.51.31.51.31.91.91.92.12.12.32.33,03,0
s0.20.20.20.20.20.20.20.30.250.30.250.30.30.30.30.30.40.40.40.4
# tracks44445666666666666699

DIN 6319 Spherical Washers

Information

DIN 6319 spherical washers are used for clamping on non-parallel surfaces.

Female washers Type G are mainly used on elongated holes.

When utilizing DIN 6330 hexagon nuts with spherical seating the male washer is redundant.

Specification

Type C / D:

Case hardened steel

  • Case hardened all round

    depth 0.2 to 0.4 mm

    hardness (550 + 100) HV 10

  • Phosphated

Type G:


Tempered steel
  • Tempered

    hardness (350 + 80) HV 30

  • Punched and trued

RoHS compliant


DIN 6319 Steel Spherical Washers sketch


DIN 6319

Adjust table
FilterAllAllAllAllAllAllAll
Descriptiond1 H13d2 H13d3d4d5d6h1
DIN 6319-6,4-C6.4-12--M 60.7
DIN 6319-8,4-C8.4-17--M 80.6
DIN 6319-10,5-C10.5-21--M 100.8
DIN 6319-13-C13-24--M 121.1
DIN 6319-15-C15-28--M 141.2
DIN 6319-17-C17-30--M 161.3
DIN 6319-21-C21-36--M 202
DIN 6319-25-C25-44--M 242.4
DIN 6319-31-C31-56--M 303.6
DIN 6319-37-C37-68--M 364.6
DIN 6319-43-C43-78--M 426.5
DIN 6319-50-C50-92--M 488
DIN 6319-7,1-D-7.1-1211M 6-
DIN 6319-9,6-D-9.6-1714.5M 8-
DIN 6319-12-D-12-2118.5M 10-
DIN 6319-14,2-D-14.2-2420M 12-
DIN 6319-16,5-D-16.5-2824.8M 14-
DIN 6319-19-D-19-3026M 16-
DIN 6319-23,2-D-23.2-3631M 20-
DIN 6319-28-D-28-4437M 24-
DIN 6319-35-D-35-5649M 30-
DIN 6319-42-D-42-6860M 36-
DIN 6319-49-D-49-7870M 42-
DIN 6319-56-D-56-9282M 48-
DIN 6319-7,1-G-7.1-1711M 6-
DIN 6319-9,6-G-9.6-2414.5M 8-
DIN 6319-12-G-12-3018.5M 10-
DIN 6319-14,2-G-14.2-3620M 12-
DIN 6319-19-G-19-4426M 16-
DIN 6319-23,2-G-23.2-5031M 20-
DIN 6319-28-G-28-6037M 24-
DIN 6319-35-G-35-6849M 30-



DIN 125A/ISO 7089 140HV STEEL
FLAT WASHER - PLAIN FINISH and ZINC PLATED

DIN 125A/7089 140HV STEEL

FLAT WASHER - BLACK, YELLOW ZINC PLATED, HOT DIP GALVANIZED and NICKEL PLATED

DIN 125B/ISO 7090 140HV STEEL

FLAT WASHER WITH CHAMFER - PLAIN FINISH, BLACK, ZINC PLATED

DIN 126/ISO 7091 100HV STEEL

FLAT WASHER - PLAIN FINISH, ZINC PLATED and HOT DIP GALVANIZED

DIN 433/ISO 7092 140HV STEEL

SMALL O/D FLAT WASHER - PLAIN FINISH and ZINC PLATED

DIN 433/ISO 7092 140HV STEEL

SMALL O/D FLAT WASHER - BLACK and YELLOW ZINC PLATED

DIN 9021/ISO 7093 140HV STEEL

LARGE O/D FLAT WASHER - BLACK, YELLOW ZINC PLATED and HOT DIP GALVANIZED

DIN 1440/ISO 8738 140HV STEEL

FLAT WASHER FOR CLEVIS PINS - ZINC PLATED

DIN 988 STEEL

SHIM WASHER - PLAIN FINISH

DIN 988 HARDENED STEEL

SHIM SUPPORT WASHER - PLAIN FINISH

DIN 125A 200HV HARDENED STEEL

FLAT WASHER (TP200) - BLACK and ZINC PLATED

K651 SPRING STEEL

CONTACT LOCK WASHER - ZINC PLATED

K652 SPRING STEEL

CONTACT LOCK WASHER - DACROMET

DIN 6319D-10 STEEL, CASE HARDENED

CONICAL SEAT WASHER

DIN 2093A/B/C HARDENED STEEL

DISC SPRINGS (BELLEVILLE) - PLAIN FINISH

DIN 6797A SPRING STEEL

EXTERNALLY TOOTHED LOCK WASHERS - BLACK and ZINC PLATED

DIN 6797I/6797J SPRING STEEL

INTERNALLY TOOTHED LOCK WASHERS - BLACK and ZINC PLATED

DIN 6798A SPRING STEEL

EXTERNALLY SERRATED LOCK WASHERS - BLACK and ZINC PLATED

DIN 6798I/6798J SPRING STEEL

INTERNALLY SERRATED LOCK WASHERS - BLACK and ZINC PLATED

DIN 6798D SPRING STEEL

DOUBLE SERRATED LOCK WASHERS - BLACK and ZINC PLATED

Chapter F -- DIN 6798V SPRING STEEL

CONICAL EXTERNALLY SERRATED LOCK WASHERS FOR COUNTERSUNK SCREWS -
BLACK and ZINC PLATED

DIN 6799 SPRING STEEL

CIRCLIP (E-CLIPS) - BLACK and ZINC PLATED

DIN 6799 SPRING STEEL

CIRCLIP (E-CLIPS) APPLICATOR TOOLS and DISPENSERS
